Modularity

• Modular design, wide transmission range and fine distribution.
• Foot or flange mounted.

Versatility

• 14 basic sizes, 07 – 17 – 27 – 37 – 47 – 57 – 67 – 77 – 87 – 97 -107 – 137 – 147 – 167.
• 3 input versions, with motor, with input shaft and with input flange.
• Wide range of different mounting positions.

Performances

• Reduction ratio range from 1.3 to 289.74.
• Output torque up to 22,500Nm.
• Motor power from 0.12kW to 160kW.

Reliability

• Sturdy cast iron housing for heavy duty applications.
• The gear is ground by high-precision gear grinding machine with stable transmission and low noise.
• High quality sealing provides good protection performance, can work continuously in harsh environments.
• The double-body reducer specially designed for special low-speed occasions, the gear ratio of the reducer can be widely extended.

Optional Accessories

• Output flanges

Catalogue

Regarding the catalogue, please check the  Downloads page.
