Modularity

• Modular design, wide transmission range and fine distribution.

Versatility

• 10 basic sizes, 025 – 030 – 040 – 050 – 063 – 075 – 090 – 110 – 130 – 150.
• Wide range of different mounting positions.

Performances

• Reduction ratio range from 5 to 100.
• Output torque up to 1,755Nm.
• Motor power from 0.06kW to 15kW.

Reliability

• Housing: die-cast aluminum alloy frame sizes 025 – 090; cast iron frame sizes 110 – 150.
• Heat sink design for cooling provides great surface area and higher thermal capacity.
• Hardened worm with fine grinding has the features of higher efficiency and big output torque.
• Low noise and stably running, can adapt long term work condition in terrible environments.
• Light weight, high mechanical strength.
• Flexibly combined with RW reducer, PC module or UD variator, the ratio can be widely extended.

Optional Accessories

• Output flange
• Extension worm shaft
• Output shaft
• Torque arm

Catalogue

Regarding the catalogue, please check the  Downloads page.
