| KP0.5 series |
 |
- Displacement: 0.19 – 2 ml/r
- Max. continuous pressure up to 200 bar
- Speed: 500 – 7,000 r/min
- Material: extruded aluminum body; die-cast aluminum cover
|
| KP1 series |
 |
- Displacement: 0.8 – 8 ml/r
- Max. continuous pressure up to 230 bar
- Speed: 600 – 6,000 r/min
- Material: extruded aluminum body; die-cast aluminum cover
|
| AP1 series |
 |
- Displacement: 1.4 – 13.8 ml/r
- Max. continuous pressure up to 250 bar
- Speed: 600 – 6,000 r/min
- Material: extruded aluminum body; die-cast aluminum cover
|
| HP1 series |
 |
- Displacement: 1.4 – 13.8 ml/r
- Max. continuous pressure up to 250 bar
- Speed: 600 – 6,000 r/min
- Material: extruded aluminum body; cast iron cover
|
| AP1.5 series |
 |
- Displacement: 2 – 12 ml/r
- Max. continuous pressure up to 210 bar
- Speed: 500 – 5,000 r/min
- Material: extruded aluminum body; die-cast aluminum cover
|
| AP2 series |
 |
- Displacement: 3 – 30 ml/r
- Max. continuous pressure up to 270 bar
- Speed: 400 – 4,000 r/min
- Material: extruded aluminum body; die-cast aluminum cover
|
| HP2 series |
 |
- Displacement: 3 – 30 ml/r
- Max. continuous pressure up to 270 bar
- Speed: 400 – 4,000 r/min
- Material: extruded aluminum body; cast iron cover
|
| AP2.5 series |
 |
- Displacement: 10 – 45 ml/r
- Max. continuous pressure up to 250 bar
- Speed: 400 – 4,000 r/min
- Material: extruded aluminum body; die-cast aluminum cover
|
| HP2.5 series |
 |
- Displacement: 10 – 45 ml/r
- Max. continuous pressure up to 250 bar
- Speed: 400 – 4,000 r/min
- Material: extruded aluminum body; cast iron cover
|
| DP2.5 series |
 |
- Displacement: 23 – 40 ml/r
- Max. continuous pressure up to 230 bar
- Speed: 500 – 3,500 r/min
- Material: cast iron body; die-cast aluminum cover
|
| HP2.6 series |
 |
- Displacement: 6 – 44 ml/r
- Max. continuous pressure up to 250 bar
- Speed: 400 – 4,000 r/min
- Material: extruded aluminum body; cast iron cover
|
| HP3 series |
 |
- Displacement: 20 – 71 ml/r
- Max. continuous pressure up to 280 bar
- Speed: 400 – 3,500 r/min
- Material: extruded aluminum body; cast iron cover
|
| AP3.5 series |
 |
- Displacement: 40 – 100 ml/r
- Max. continuous pressure up to 250 bar
- Speed: 500 – 2,750 r/min
- Material: cast iron body; die-cast aluminum cover
|
|
| Multiple Pumps |
 |
- Possible combination: KP0.5/0.5, HP1/1, KP1/1, HP2/2/2, HP2/2, HP2/1, HP2/0.5, HP2.6/2.6, HP3/3, HP3/2, HP3/1, HP3/0.5
- Displacement: 0.38 – 140 ml/r
- Max. continuous pressure up to 200 bar
|
